Description
Part Notes: This product is not designed for use with 21″ or 23″ front wheels. Requires the use of Harley Davidson upper fork tubes OEM P/N 83804-09 (22.55″ long). Due to the nature of the design, this front end kit will raise the overall ride height of the motorcycle. ’97-’01 models equipped with stock air forks will require additional purchase of Harley Davidson OEM P/N’s 45419-80 (2) and 45733-48 (2) to install. Part #0414-0597 requires the use of Harley-Davidson upper fork tubes OEM #83804-09 (22.55″ L).
Features:
Performance spring rate delivers agile handling for aggressive riders without sacrificing comfort
Specifically designed to increase ride height on FL touring models
Imporves cornering clearance, lean angles, and eliminates dragging floorboards and footpegs
Improves straight-line stability, high-speed cornering, and maneuverability
Increases resistance to bottoming out on large bumps or potholes
Threaded pre-load adjuster allows tuning for various rider weights and increased pre-load range
Reduces front-end dive and improves front tire traction under aggressive braking
Designed for optimum performance with Legend’s 14″ Revo-Arc rear suspensions
Includes two 2″ over monotube, dual chambered damper cartridges, and two top out springs
Designed to be used with stock diameter front wheels
For Extended Fork Tubes.
Specifications:
Length: Two Inches Longer Than Stock
Color/Finish: Black
Height Adjustment: Extends 50.80 mm / Extends 2.00″
Riding Style: Street
Material: Billet Aluminum
Model: AXEO Performance (+2″)
Style: Extended Fork Tubes
Type: Preload Adjustable Monotube
Units: Kit
Fork Tube Diameter: 41.00 mm
Product Name: Cartridge
Fitment:
| Year | Make | Model |
| 2010 | Harley-Davidson | FLHTCUSE5 CVO Ultra Classic Electra Glide |
